Detección de movimiento 2.0
- Human/Vehicle Analysis
- Deep learning based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
- Quick search by object or event type is supported;

Video and Audio
- Entrada de vídeo IP
-2-ch (up to 10-ch)
- Up to 5MP resolution
- Support H.265+/H.265/H.264+/H.264 IP cameras
- Entrada de video analógic
- 8-ch
- BNC interface (1.0 Vp-p, 75 O), supporting coaxitron connection
- HDTV Input1080p25, 1080p30, 720p25, 720p30
- AHD Input1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputSupport
- HDMI Output
- 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Video Output ModeHDMI/VGA simultaneous output

Entrada de Audio
- 1-ch RCA (2.0 Vp-p, 1 KO)
- 8-ch via coaxial cable
- Salida de audio1-ch, RCA (Linear, 1 KO)
- Two-Way AudioReuse the first audio input
- Reproducción síncrona8-ch

Recording
- Compresión de vídeoH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Resolución de codificación
- For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
- For 720p stream access: 720p/WD1/4CIF/VGA/CIF
- For SD stream access: WD1/4CIF/VGA/CIF
- Frame Rate

Main stream
- For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
- For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
- For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
- Sub-stream:
- For 1080p and 720p stream access CIF/QVGA@15 fps
- For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
- Vídeo bitrate32 Kbps to 4 Mbps
- Stream TypeVideo, Video & Audio
- Compresión de audioG.711u
- Audio Bitrate64 Kbps

Red
- Conexión remota64
- Protocolo de redTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™, HTTPS
Total Bandwidth72 Mbps
Interfaz de red1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface
- SATA1 SATA interface
- CapacidadUp to 4 TB capacity for each disk
- Interfaz USBRear panel: 2 × USB 2.0
- Alarma E/SN/A

General
- Fuente de alimentación12 VDC, 1.5 A
- Consumo= 10 W (without HDD)
- Temperatura de trabajo-10 °C to 55 °C (14 °F to +131 °F)
- Condiciones de Humedad10% to 90%
- Dimensión (W × D × H)263 × 220 × 48 mm (10.3 × 8.7 × 1.9 inch)
