- Detección de movimiento 2.0
- Human/Vehicle Analysis
- Deep learning based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
- Quick search by object or event type is supported;

Video and Audio
- Entrada de vídeo IP
- 1-ch (up to 5-ch)
- Up to 2MP resolution
- Support H.265+/H.265/H.264+/H.264 IP cameras

Entrada de video analógico
- 4-ch
- BNC interface (1.0 Vp-p, 75 O), supporting coaxitron connectio
- HDMI Output
- 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output
- 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- CVBS Input: Support
- HDTVI Input: 1080p25, 1080p30, 720p25, 720p30
- Reproducción síncrona: 4-ch
- AHD Input: 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
- Video Output Mode: HDMI/VGA simultaneous output
- Salida de audio: 1-ch, RCA (Linear, 1 KO)

Entrada de Audio
1-ch RCA (2.0 Vp-p, 1 KO)
4-ch via coaxial cable
Two-Way Audio: Reuse the first audio input

Recording
Compresión de vídeo: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Resolución de codificación
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
For 720p stream access: 720p/WD1/4CIF/VGA/CIF
For SD stream access: WD1/4CIF/VGA/CIF

Main stream:
- For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@25 fps(P)/30 fps (N)
- For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
- For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
- Sub-stream: 4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)
- Vídeo bitrate: 32 Kbps to 4 Mbps
- Stream Type: Video, Video & Audio
- Compresión de audio: G.711u
- Audio Bitrate: 64 Kbps

Red
- Total Bandwidth: 64 Mbps
- Protocolo de red: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS
- Conexión remota: 32
- Interfaz de red: 1, RJ45 10/100 Mbps self-adaptive Ethernet interface

- Auxiliary Interface
- SATA: 1 SATA interface
- Capacidad: Up to 4 TB capacity for each disk
- Interfaz USB: Rear panel: 2 × USB 2.0
- Alarma E/S: N/A

General
- Fuente de alimentación: 12 VDC, 1.5 A
- Consumo: = 10 W (without HDD)
- Temperatura de trabajo: -10 °C to 55 °C (14 °F to +131 °F)
- Condiciones de Humedad: 10% to 90%
- Dimensión (W × D × H): 263 × 220 × 48 mm (10.3 × 8.7 × 1.9 inch)
- Peso: = 0.8 kg (without HDD, 1.8 lb.)
