Camera
- Resolution Dual 2K+ Resolution
- Image sensor 1/3" Progressive Scan CMOS
- Shutter Speed Self-adaptive shutter
- Fixed Lens 2.8mm@F1.6 , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
- PT Lens 6mm@F1.6 , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
- Lens Mount M12
- Day & Night IR-cut filter with auto-switching
- DNR 3D DNR
- WDR Digital WDR

Compression
- Video Compression H.264/H.265
- Video/Audio Bit Rate Adaptive bit rate.

- Max. Resolution 2560 × 1440
- Frame Rate Max:30fps; Self-Adaptive during network transmission

Network
- Smart Alarm Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
- Wi-Fi Pairing AP paring
- Protocol EZVIZ cloud proprietary protocol
- Interface Protocol EZVIZ cloud proprietary protocol

Interface
- Storage Micro SD card slot (Max. 512G)
- Power TYPE-C
- Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Wi-Fi
- Standard IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
- Frequency Range 2.4GHz: 2.4 GHz ~ 2.4835 GHz / 5GHz: 5.15GHz~5.25GHz
- Channel Bandwidth 2.4GHz Supports 20MHz / 5GHz Supports 80MHz
- Security WPA-PSK, WPA2-PSK, WPA3-Personal
- Transmission Rate:
2.4GHz Max. Rate Support: 11b_11M,11g_54M,11n_MCS7_20M,11ax_MCS11_20M
5.15-5.25GHz Max. Rate Support: 11a_54M,11n_MCS7_20-40M,11ac_MCS9_20-40-80M,11ax_MCS11_20-40-80M
- Output Power (EIRP) 20 dBm
- Antenna Gain 2.56dBi@2.48GHz,3.18dBi@5.22GHz

General
- Operating Conditions -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
- Power Supply DC 5V/2A
- Power Consumption 8W max
- IR Range MAX. 10 meters(32.81ft)
- Dimensions 88mm x 88mm x 131.5mm (3.46” x 3.47” x 4.69”)
- Package Dimensions
- Net Weight 254.5g
